CGO Conventional Electrical Steel M3/M4/M5/M6
We produce cold rolled grain oriented sheet (CRGO), also known as transformer sheet. They are made of 3% silicon steel. There are four grades of CRGO sheet: 0.23mm (M3), 0.27mm (M4), 0.30mm (M5), 0.35mm (M6).
- Product Description
- Spot Warehouse
- Product Inspection
- Product Measurement
- Product Packaging
-
- Commodity name: CGO Conventional Electrical Steel M3/M4/M5/M6
We produce cold rolled grain oriented sheet (CRGO), also known as transformer sheet. They are made of 3% silicon steel. There are four grades of CRGO sheet: 0.23mm (M3), 0.27mm (M4), 0.30mm (M5), 0.35mm (M6).
CGO Conventional Electrical Steel M3/M4/M5/M6 Description
We produce cold rolled grain oriented sheet (CRGO), also known as transformer sheet. They are made of 3% silicon steel. Contains four grades of CRGO sheet:
AISI ASTM Thickness in mm M3 23G045 0.009 0.23 M4 27G051 0.011 0.27 M5 30G058 0.012 0.30 M6 35G066 0.014 Product Parameters
Category Silicon Content/%
Nominal Thickness/Mm
Lord To Use Way
Hot Rolled Silicon Steel
(No Orientation)
Hot rolled low silicon steel(Motor Steel)
1.0~2.5
0.5
Household motors and micromotors
Hot rolled high silicon steel(Transformer steel)
3.0~4.5
0.35,0.50
Transformer
Cold Rolled Electrical Steel
Cold rolled non-oriented electrical steel(Motor Steel)
Low carbon electrical steel
≤ 0.5
0.50,0.65
Small transformers and ballasts for household motors, micromotors
Silicon steel
>0.5~3.5
0.35,0.50
Medium and large motors, generators and transformers
Cold rolled grain oriented silicon steel(Transformer steel)
Ordinary oriented silicon steel
2.9~3.3
0.18,0.23,0.27
0.30,0.35Large, medium and small transformers and ballasts
High magnetic induction oriented silicon steel
Special Purpose Silicon Steel
Cold rolled grain oriented silicon steel strip
2.9~3.3
0.03,0.05,0.10
Pulse transformer, magnetic amplifier, high frequency transformer and electric welding machine
Cold rolled non-oriented silicon steel strip
3.0
0.15,0.20
High-frequency motors and generators
Cold rolled non-oriented silicon steel for magnetic switch
3.0
0.70
Relays and magnetic switches
Cold rolled high silicon steel
6.5
0.1~0.5
High-frequency motors, transformers and magnetic shielding
Scope of Application
The main application field of grain-oriented electrical sheet is the iron core of power and distribution (distribution) transformers. In addition, they are also used in the production of: current transformers, voltage transformers, medium and large high-efficiency generators, reactors, magnetic screens, wound cores, audio transformers, etc.
-
CGO Conventional Electrical Steel M3/M4/M5/M6 - Stock Warehouse
-
CGO Conventional Electrical Steel M3/M4/M5/M6 - Product Inspection
Tensile Strength Testing Tensile Strength Testing Physical Performance Testing Chemical Composition Testing
Inspection Hardness Testing Spectral Detection Mechanical Properties -
CGO Conventional Electrical Steel M3/M4/M5/M6 - Product Measurement
Thickness measurement Thickness measurement Thickness measurement Thickness measurement
Thickness measurement Thickness measurement Thickness measurement Width measurement -
CGO Conventional Electrical Steel M3/M4/M5/M6 - Product Packaging
Baowu Special steel
Your reliable steel supplier
Baowu Special steel has 10+ warehouses with ready stock. The annual supply capacity is approximately 10 million tons. It has 10 years of experience in large-scale project supply. The customer reorder rate reaches 86%. We ensure quality and quantity, provide material certificates, and will refund if the products are not qualified, so please be assured the purchase.
