Prepainted Galvalume Steel PPGL Sheet
Prepainted galvalume steel coils are a type of coated steel product that combines galvalume steel's corrosion resistance with the aesthetics and versatility of pre-painted coatings. Galvalume steel is created by covering a steel substrate with a zinc-aluminum alloy, which has high corrosion resistance and durability.
- Product Description
- Spot Warehouse
- Product Inspection
- Product Measurement
- Product Packaging
-
- Commodity name: Prepainted Galvalume Steel PPGL Sheet
Prepainted galvalume steel coils are a type of coated steel product that combines galvalume steel's corrosion resistance with the aesthetics and versatility of pre-painted coatings. Galvalume steel is created by covering a steel substrate with a zinc-aluminum alloy, which has high corrosion resistance and durability.
Prepainted Galvalume Steel PPGL Sheet Description
Color coated board can be divided into ordinary PE, high corrosion resistant HDP, high corrosion resistant silicon modified polyester SMP, high corrosion resistant fluorocarbon PVDF, super corrosion resistant nano fluorocarbon PVDF, aluminum magnesium manganese color coated board, printing color coated board, etc.
The varieties that can be produced are: ordinary building materials board, purification board, cold storage board, solar panel, door and window profile, household appliance board, writing board, printing board, reticulated suede color coating, embossed printing, aluminum magnesium manganese color coating board, high weather resistance, silicon modification, self-cleaning board, heat reflection board, antibacterial board, acid and alkali resistant color coating board, etc., which can meet customer requirements of different industries.
Product Parameters
Product Name
Prepainted Galvalume Steel PPGL Sheet
Thickness
0.12mm-1.2mm
Width
600mm-1250mm
Length
Support Customization
Color
According RAL Color Card (Can provide custom pattern)
Paint
PE, SMP, HDP, PVDF
Primer
Epoxy Primer, Polyester primer, Water soluble acrylic primer, Polyurethane Primer
Coating Thickness
Top: 11-35μm, Back: 5-14μm
Color Selection
We provide many colors to choose from, the following are common colors, if you like other colors or patterns, please send us the RAL color code.
Advantages of Color Coated Plate
Custom Colors
You can choose any RAL color, as well as customize the pattern according to your needs. The beautiful surface makes the color coated board decorative. So it can be directly used in many fields.
Tough Soating
Color coated steel plate including PPGL plate PPGI steel, the use of continuous coil coating, the surface luster bright, no cracking, no peeling. In addition, it can keep the color for at least 10 years.
Excellent Mechanical Properties
The color coated plate retains the mechanical properties of the base metal, such as tensile strength. In addition, the application of the coating can protect the surface from rust, thereby extending its service life. Studies have shown that the service life of color-coated steel sheets is 50% longer than that of galvanized steel sheets.
Easy to Use
Different from the coil, the color coated plate is a kind of finished product. This means that it can be directly used in many industries. Considering its light weight, it is easy to carry and install. In addition, due to its aesthetic appearance, no additional decoration is required. Also, less maintenance is required during the service life.Coating Type
In the coil coating, the durability of the role is the resin and pigment, the most commonly used finish polyester, silicon modified polyester, high durability polyester and polyvinylidene fluoride.
Polyester PE
Good adhesion, rich color, wide range in formability and outdoor durability, medium chemical resistance, low cost.
Silicon Modified Polyester SMP
The hardness, abrasion resistance and heat resistance of the coating film are good; as well as good external durability and powder resistance, gloss retention, general flexibility and medium cost.
High Durability Polyester HDP
Excellent color retention and UV resistance, excellent outdoor durability and chalking resistance, good film adhesion, rich color, excellent cost performance.
Polyvinylidene Fluoride PVDF
Excellent color retention and UV resistance, excellent outdoor durability and chalking resistance, excellent solvent resistance, good formability, dirt resistance, limited color, and high cost. -
Prepainted Galvalume Steel PPGL Sheet - Stock Warehouse
-
Prepainted Galvalume Steel PPGL Sheet - Product Inspection
Tensile Strength Testing Tensile Strength Testing Physical Performance Testing Chemical Composition Testing
Inspection Hardness Testing Spectral Detection Mechanical Properties -
Prepainted Galvalume Steel PPGL Sheet - Product Measurement
Thickness Measurement Width Measurement Measurement Measurement -
Prepainted Galvalume Steel PPGL Sheet - Product Packaging
Baowu Special steel
Your reliable steel supplier
Baowu Special steel has 10+ warehouses with ready stock. The annual supply capacity is approximately 10 million tons. It has 10 years of experience in large-scale project supply. The customer reorder rate reaches 86%. We ensure quality and quantity, provide material certificates, and will refund if the products are not qualified, so please be assured the purchase.
