Rudder Stock - Marine Forgings
Rudder stock, also called rudder pintle, after Rudder Stock roughing, it will be conducted for the aging treatment, NDT Inspection and taper surface to scratch with. Rudder stock also known as rudder pulling rod,Rudder Stock is a part of rudder system. Rudder system include rudder blade, rudder stock, rudder pintle, carriers ,bearings and other accessories. It is a very important part of steering system. It make sure the vessel change direction.
- Product Description
- Spot Warehouse
- Product Inspection
- Product Measurement
- Product Packaging
-
- Commodity name: Rudder Stock - Marine Forgings
Rudder stock, also called rudder pintle, after Rudder Stock roughing, it will be conducted for the aging treatment, NDT Inspection and taper surface to scratch with. Rudder stock also known as rudder pulling rod,Rudder Stock is a part of rudder system. Rudder system include rudder blade, rudder stock, rudder pintle, carriers ,bearings and other accessories. It is a very important part of steering system. It make sure the vessel change direction.
Rudder Stock - Marine Forgings Description
Marine rudder stock also was known as rudder pulling rod. Marine rudder stock is a part of rudder system. Rudder system include rudder stock, rudder pintle, rudder blade, stern shaft, propeller shaft, intermediate shaft etc. It is a very important part of steering system because it makes sure the vessel change direction. Marine forged rudder stocks are made from high-strength materials such as steel, and are typically manufactured using a forging process, which involves heating the metal and shaping it using pressure or impact. This process results in a strong, durable, and reliable rudder stock that can withstand the stresses and forces associated with steering a vessel.
The rudder stock is also named the rudder shaft, which connects the steering gear with the rudder blade; the rudder stock transmits the steering gear’s turning force to the rudder blade to steer the ship. Usually, the rudder stock is made of forged steel. The rudder stock connects to the rudder blade by hydraulic cone fit or flange coupling; and connects to the tiller by hydraulic cone fit, a key connection, or by clamping rings for smaller rudders. Stainless steel sleeves are fitted in the way of bearings to protect the stock from getting damaged.
Material Forged Steel Test 100% Ultrasonic Flaw Detection Test Certificate ABS, BV, DNV, GL, LR,NK, RINA,KR, CCS, etc. Inspection Chemical Composition; UT,MT; Mechanical Property; Dimension Check Forging Processing Ingot—forging—heat treatment—rough machining—UT.MT—Q+T—inspection—finishing machining—UT.MT—packing Heat Treatment Normalized / Annealed / Quenched / tempered -
Rudder Stock Marine Forgings - Stock Warehouse
-
Rudder Stock Marine Forgings - Product Inspection
Stress-rupture-testing Tensile-testing Hardness-testing Chemical Composition Testing
Inspection Magnetic-particle-inspection Charpy-impact-testing Ultrasonic-testing -
Rudder Stock Marine Forgings - Product Measurement
Measurement Measurement Measurement Measurement
Measurement Measurement Measurement Measurement -
Rudder Stock Marine Forgings - Product Packaging
Baowu Special steel
Your reliable steel supplier
Baowu Special steel has 10+ warehouses with ready stock. The annual supply capacity is approximately 10 million tons. It has 10 years of experience in large-scale project supply. The customer reorder rate reaches 86%. We ensure quality and quantity, provide material certificates, and will refund if the products are not qualified, so please be assured the purchase.
